CSS grid-row-gap Property

The grid-row-gap property sets the gap size between the rows of grid elements. The gap width can be specified, separating the rows by using a value for grid-row-gap.

It can be specified both in "px" and percentages.

The row-gap property is now replacing the prefixed grid-row-gap property. But grid-row-gap is still needed for the browsers that applied the prefixed property instead of row-gap.

Initial Value normal
Applies to Multi-column elements, flex containers, grid containers.
Inherited No.
Animatable Yes. Gap between the rows is animatable.
Version CSS Grid Layout Module Level 1
DOM Syntax object.style.gridRowGap = "30px";

Syntax

grid-row-gap: normal | length;

Example of the grid-row-gap property:

<!DOCTYPE html>
<html>
  <head>
    <title>Title of the document</title>
    <style>
      .grid-container {
      display: grid;
      grid-template-columns: auto auto auto auto;
      grid-column-gap: 20px;
      grid-row-gap: 0;
      background-color: #666;
      padding: 10px;
      }
      .grid-container > div {
      background-color: #eee;
      text-align: center;
      padding: 20px 0;
      font-size: 30px;
      }
    </style>
  </head>
  <body>
    <h2>Grid-row-gap property example</h2>
    <div class="grid-container">
      <div>1</div>
      <div>2</div>
      <div>3</div>
      <div>4</div>
      <div>5</div>
      <div>6</div>
      <div>7</div>
      <div class="box8">8</div>
    </div>
  </body>
</html>

Result

Here, the gap between rows is specified as 0. In the next example, the gap between rows is 40px.

Example of the grid-row-gap property specified in pixels:

<!DOCTYPE html>
<html>
  <head>
    <title>Title of the document</title>
    <style>
      .grid-container {
      display: grid;
      grid-template-columns: auto auto auto auto;
      grid-column-gap: 20px;
      grid-row-gap: 40px;
      background-color: #666;
      padding: 10px;
      }
      .grid-container > div {
      background-color: #eee;
      text-align: center;
      padding: 20px 0;
      font-size: 30px;
      }
    </style>
  </head>
  <body>
    <h2>Grid-row-gap property example</h2>
    <div class="grid-container">
      <div>1</div>
      <div>2</div>
      <div>3</div>
      <div>4</div>
      <div>5</div>
      <div>6</div>
      <div>7</div>
      <div>8</div>
      <div>9</div>
      <div>10</div>
      <div>11</div>
      <div>12</div>
    </div>
  </body>
</html>

Example of the grid-row-gap property specified in percentage:

<!DOCTYPE html>
<html>
  <head>
    <title>Title of the document</title>
    <style>
      .grid-container {
      display: grid;
      grid-template-columns: auto auto auto;
      grid-row-gap: 15%;
      grid-column-gap: 3%;
      background-color: grey;
      padding: 40px;
      }
      .grid-container > div {
      background-color: white;
      text-align: center;
      padding: 25px;
      font-size: 20px;
      }
    </style>
  </head>
  <body>
    <div class="grid-container">
      <div>1</div>
      <div>2</div>
      <div>3</div>
      <div>4</div>
      <div>5</div>
    </div>
  </body>
</html>

Values

Value Description
normal Uses the browser’s default spacing between the rows. This is the default value of this property.
length The gap between rows is specified in px or percentages. Negative values are not allowed. Default value is 0.
initial Makes the property use its default value.
inherit Inherits the property from its parents element.
